Insecure Design: An In-Depth Guide with Example

Insecure Design is a type of security vulnerability that arises from poor architectural decisions or design flaws in an application or system. This vulnerability happens when security considerations are either not properly integrated into the design phase or are neglected altogether, leaving the system prone to various types of attacks. Unlike many other vulnerabilities, insecure design stems from decisions made during the design or architecture of the system, which means it can be more difficult to fix once the application is already developed.

In this blog post, we’ll explore what insecure design is, provide detailed examples of how it can manifest, and outline ways to prevent it.

What is Insecure Design?

Insecure design refers to security weaknesses that are the result of flaws in the system’s design. These flaws may occur because security was not considered adequately during the planning phase or because security principles were violated while architecting the application. The issue with insecure design is that it is a systemic flaw—meaning it originates at the foundation of the application and can affect the entire system.

Some examples of insecure design include:

• Poor authentication design.
• Lack of encryption for sensitive data.
• Inadequate access control or authorization.
• Exposure of unnecessary data or functionality.

Examples of Insecure Design with Real-World Scenarios

Example 1: Insufficient Authentication and Session Management

Imagine an online banking application that allows users to log in with just a username and password. However, the application does not require users to change their passwords periodically, nor does it implement multi-factor authentication (MFA). Additionally, the session management mechanism allows sessions to remain active indefinitely without expiration, making it vulnerable to session hijacking.

An attacker who gains access to a valid session (e.g., through a stolen session cookie) can continue to access the victim’s account, even after they’ve logged out, as the session never expires.

How to Fix:

• Enforce strong authentication policies, including MFA and password complexity requirements.
• Implement session timeouts to automatically expire inactive sessions after a certain period.
• Store session tokens securely (e.g., HTTP-only, SameSite cookies) and ensure they are invalidated on logout.

Example 2: Poor Access Control and Authorization

Consider a healthcare application that allows employees to view patient records. In the design phase, the system is set up so that anyone who can log into the system is granted access to patient data. There’s no concept of roles or permissions, and access control is not enforced. As a result, any user, regardless of their role (e.g., an administrative assistant), can view or edit patient data.

This flaw in design allows unauthorized access to sensitive data, such as medical histories, which could lead to data breaches or unauthorized data modifications.

How to Fix:

• Implement Role-Based Access Control (RBAC) or Attribute-Based Access Control (ABAC) to ensure that only authorized users can access specific data or actions based on their role or attributes.
• Always check user permissions on the server side before serving sensitive data or allowing specific actions.

Example 3: Lack of Encryption for Sensitive Data

An e-commerce platform stores user credit card information in a database without encrypting it. The application may also send sensitive data over HTTP instead of HTTPS. If attackers gain access to the database or intercept traffic (via man-in-the-middle attacks), they could steal users’ credit card information.

The failure to encrypt sensitive data both in transit and at rest leaves the platform vulnerable to data breaches and fraud.

How to Fix:

• Use encryption to protect sensitive data both at rest and in transit (e.g., AES for data at rest and TLS/SSL for data in transit).
• Always use HTTPS for all communication between clients and servers.
• Store passwords and other sensitive information using strong hashing algorithms (e.g., bcrypt, PBKDF2) rather than plaintext storage.

Example 4: Exposing Sensitive Functionality to the Frontend

A mobile app has an API endpoint that retrieves a user’s profile data. However, the backend API does not verify whether the logged-in user is requesting their own data. The design flaw exposes this functionality to all users. As a result, an attacker could reverse-engineer the app and send requests to the endpoint with another user’s credentials, thereby accessing their private profile data.

How to Fix:

• Ensure that all sensitive actions are authorized on the server-side and that access control checks are performed before exposing sensitive data.
• Use signed tokens or session identifiers to validate that the user requesting the data has permission to view it.
• Always validate and sanitize inputs from the client-side to prevent unauthorized access to sensitive resources.

Example 5: Excessive Exposure of Services

Imagine an IoT system where a device, like a smart home thermostat, is designed to expose an API to external services for remote management. However, the design includes overly permissive functionality, allowing remote users to change not just the temperature settings but also access sensitive functions like security settings or unlock doors. This overexposure increases the attack surface and makes it easier for an attacker to exploit the system.

How to Fix:

• Limit the exposure of critical system functionalities to authorized users only. Apply the principle of least privilege to minimize the risk of attackers gaining access to sensitive features.
• Use proper API security practices, such as OAuth, for secure authorization and access control.

Why Insecure Design is Dangerous

Insecure design is particularly dangerous because the flaws are deeply embedded in the system’s architecture. Once the design is established, fixing insecure design requires significant changes, which can be costly and complex. Some of the dangers of insecure design include:

1. Data Breaches: Sensitive data, such as personal information, financial details, and health records, can be exposed due to improper handling.
2. Privilege Escalation: Poor access control can allow attackers to gain unauthorized access to higher privilege levels, such as admin rights, leading to system compromise.
3. Business Continuity Risk: If attackers exploit insecure design flaws to disrupt services or steal data, it can severely impact the organization’s ability to operate.
4. Reputation Damage: A breach resulting from insecure design can damage customer trust and harm the organization’s reputation, leading to financial losses and regulatory penalties.

How to Prevent Insecure Design

1. Security by Design:
   • Incorporate security principles early in the design process. Security should be an integral part of the system’s architecture, not an afterthought.
   • Perform threat modeling during the design phase to identify potential vulnerabilities and address them proactively.
2. Apply the Principle of Least Privilege:
   • Ensure users and services have the minimum level of access needed to perform their tasks. This limits the potential damage from a compromised account or service.
3. Use Strong Authentication and Access Control:
   • Implement strong authentication mechanisms, such as multi-factor authentication (MFA), to verify user identity.
   • Apply role-based access control (RBAC) and other access control models to limit access based on users’ roles and permissions.
4. Encrypt Sensitive Data:
   • Always use encryption for both data at rest and data in transit to protect sensitive information from unauthorized access.
5. Regular Security Audits:
   • Conduct regular security reviews, including code reviews, penetration testing, and vulnerability scanning, to identify and address insecure design flaws before they are exploited.
6. Education and Awareness:
   • Ensure that the development team is well-versed in secure design principles and that security best practices are followed throughout the application lifecycle.

Conclusion

Insecure design is a critical vulnerability that stems from poor architectural choices or neglected security during the design phase of an application. Unlike coding errors or configuration issues, insecure design flaws are often foundational, making them challenging to fix after the system is built. It is crucial for developers and organizations to integrate security into the design phase, follow best practices for secure architecture, and regularly test their systems for vulnerabilities.

By incorporating secure design practices, such as encryption, strong authentication, and access control, and conducting thorough threat modeling, you can reduce the risk of insecure design and build robust, secure applications.
